Davitu TeSys D LRD3355 Thermal Overload Relay 30-40 Ampere For Three Phase AC Motor Protection Adjustable Settings

Why you'll like it

  • Enhanced Motor Safety — Advanced differential design detects phase failure and prevents motor burnout from load unbalance.
  • Flexible Operation — Supports both manual and automatic reset modes with an integrated test trip function for easy maintenance.
  • Precision Protection — Adjustable 30-40 Ampere thermal range with Class 10A tripping characteristics for reliable heavy-duty performance.
  • Versatile Integration — Includes one normally open and one normally closed auxiliary contact for seamless compatibility with standard contactors.

Product details

Description

The Davitu TeSys D LRD3355 Thermal Overload Relay is an essential industrial component engineered for robust motor protection. Designed specifically for three-phase AC circuits, this differential relay guards sensitive equipment against thermal overloads and phase failures that can lead to motor burnout. With a thermal adjustment range of 30 to 40 Amperes and a Class 10A tripping characteristic, it ensures rapid response to electrical faults, tripping within 10 seconds during a 600 percent overload scenario.

This high-performance relay is built for reliability in demanding environments, operating efficiently across temperatures from -20 degrees Celsius to 60 degrees Celsius. It features both normally open and normally closed auxiliary contacts for versatile integration into your control system. Compatible with major contactor series such as the LC1D80 and LC1D95, this unit supports both manual and automatic reset modes, providing flexibility for various industrial setups. Whether you are maintaining existing infrastructure or building new control panels, this authentic component provides the precise protection necessary for consistent operational safety. It is rated for insulation voltages up to 1000 Volts, making it a dependable choice for heavy-duty electrical applications.

How to use

  1. Mount the relay directly onto the compatible contactor base.
  2. Adjust the dial to the required current range between 30 and 40 Amperes based on your motor's full load current.
  3. Connect the 1NO and 1NC auxiliary contacts to your control circuit as per your system wiring diagram.
  4. Ensure the device is set to either manual or automatic reset mode depending on your operational requirements.

Ingredients

Constructed from high-grade industrial-rated thermoplastic housing, copper alloy internal contact points, and bimetallic thermal sensing elements.

As printed by the brand. Check the pack label if you have an allergy.

Specifications

BrandDAVITU
CategoryCamcorders
Ships fromUSA (sourced directly), checked in Navi Mumbai
Sold byDropy.in

Ratings & reviews

From our customers

No reviews yetBe the first to review this product.
Write a reviewDavitu TeSys D LRD3355 Thermal Overload Relay 30-40 Ampere For Three Phase AC Motor Protection Adjustable Settings

Customers Also Bought

View all

FAQs

What is the primary function of the LRD3355 thermal overload relay?

This relay is designed to protect three-phase AC motors from damage caused by thermal overloads, phase failures, and load imbalances. It cuts off the power to the motor when it detects abnormal electrical conditions, preventing burnout.

Is this relay compatible with LC1D80 and LC1D95 contactors?

Yes, the LRD3355 is specifically designed to mount directly onto TeSys D contactors, including the LC1D80 and LC1D95 models, ensuring a secure and efficient connection.

Does this unit feature manual or automatic reset?

The device includes a flexible reset selector, allowing you to choose between manual and automatic reset modes to suit your specific industrial control application needs.

Are the products sold on Dropy authentic imports?

Yes, all products offered by Dropy are authentic USA-imported goods. We source our inventory directly from verified suppliers to ensure our Indian customers receive genuine, high-quality components.

What is the operating temperature range for this relay?

This thermal overload relay is engineered to operate reliably in ambient temperatures ranging from -20 degrees Celsius to 60 degrees Celsius.
